Apartment Style – FMU FMC Horizontal Fan Coil (Pancake Style)

Description

Apartment Style

Model : FMU FMC Horizontal Fan Coil (Pancake Style)

ALL MODELS

  •  Horizontal application only
  • Accessory field−installed electric heat kits available in 5, 7.5, or 10 kW
  • 40 VA 208/230v−1−60 transformer
  • Horizontal return applications require field fabricated bottom cover
  • Cabinets meet the requirement of 2% cabinet leakage rate at 1−in. w.c. of static pressure
  • Cabinets constructed to prevent cabinet sweating
  • Refrigerant lines and electrical connections can be run out the back or side of casing

WAMC

  • 1−1/2, 2, 2−1/2 and 3 Tons
  • R−410A piston or R−22 with accessory R−22 TXV

WATC

  • 1−1/2, 2, and 2−1/2 Tons
  • R−410A TXV standard or R−22 with accessory R−22 TXV
PERFORMANCE
  • PSC motor on all models
EASY TO INSTALL AND SERVICE
  • A−coil design for maximum surface area
  • Multiple electrical, refrigerant lineset and drain line entry for application flexibility
  • Primary and secondary drain connections exit from the back or side of the cabinet
  • Supports furred−down ceiling open return and ducted return applications
  • Sweat connections for long term reliability
  • Grooved copper tube /aluminum fin coils

LIMITED WARRANTY

  • 5 year parts limited warranty
  • * For owner occupied, residential applications only. See warranty certificate for complete details and restrictions, including warranty coverage for other applications.
Title Type Size
Product Specifications application/pdf 1 MB
WAMC WATC 49603810000 application/pdf 212 KB
